GM-DX975
Pioneer GM-DX975 5 Channel Amplifier, 75 Watts x 4 + 350 Watts x 1
$419.99 CAD
This is the Pioneer GM-DX975 5 Channel Car Audio Amplifier.
Product Overview
2,000 Watts Max Power
High Quality Textured Aluminum Panel and Tough Frame
Variable High Pass and Low-Pass Filters
Gold-plated RCA Terminals
Hi-Res Audio Capable
Bass Boost Remote included
2,000 Watts Max Power
High Quality Textured Aluminum Panel and Tough Frame
Variable High Pass and Low-Pass Filters
Gold-plated RCA Terminals
Hi-Res Audio Capable
Bass Boost Remote included
What’s in the Box
5-Channel amplifier
Three 30-amp ATO fuses (installed)
Bass Boost Remote Control
Bass Boost Remote Control Cable
Speaker Level to RCA Input Adapter
Installation Screws X 4
Wire Terminal Tool x 2
Owner's manual (English/ French)
1 Year Warranty Sheet
Three 30-amp ATO fuses (installed)
Bass Boost Remote Control
Bass Boost Remote Control Cable
Speaker Level to RCA Input Adapter
Installation Screws X 4
Wire Terminal Tool x 2
Owner's manual (English/ French)
1 Year Warranty Sheet
Performance
2 ohm to 8 ohm allowable load impedance
50 Hz - Frequency bass boost
4 Ohm - 5.2A (5Ch) average current consumption (amps x #ch)
HPF - A/B Ch 40Hz-500Hz / LPF - A/B Ch 40Hz-500Hz crossover network subwoofer channel
-12dB, 24 dB/oct crossover network subwoofer slope
10 Hz ~ 500 Hz frequency response – subwoofer channel
10 Hz to 50 kHz (+0dB,-3dB) A/B Ch frequency response channel
200 mV to 6.5 V - RCA / 0.8 V to 16 V - Speaker input level @ max gain
2 Ohm - 100W x 4 + 600W x 1 / 4 Ohm - 75W x 4 + 350W x 1 / 4 Ohm Bridged - 200W x 2 + 350W x 1 nominal power output
6 channel RCA input
75 dBA (Reference: 1 W into 4 ohm) signal to noise
=/< 1% ( 20 Hz to 240 Hz) THD - Subwoofer
50 Hz - Frequency bass boost
4 Ohm - 5.2A (5Ch) average current consumption (amps x #ch)
HPF - A/B Ch 40Hz-500Hz / LPF - A/B Ch 40Hz-500Hz crossover network subwoofer channel
-12dB, 24 dB/oct crossover network subwoofer slope
10 Hz ~ 500 Hz frequency response – subwoofer channel
10 Hz to 50 kHz (+0dB,-3dB) A/B Ch frequency response channel
200 mV to 6.5 V - RCA / 0.8 V to 16 V - Speaker input level @ max gain
2 Ohm - 100W x 4 + 600W x 1 / 4 Ohm - 75W x 4 + 350W x 1 / 4 Ohm Bridged - 200W x 2 + 350W x 1 nominal power output
6 channel RCA input
75 dBA (Reference: 1 W into 4 ohm) signal to noise
=/< 1% ( 20 Hz to 240 Hz) THD - Subwoofer
